CSFP BiDi 1GE MR 1550nm/1310nm 20km 14dB I-temp LC
A 20km 1Gbps Dual-BiDi CSFP transceiver solution
Product information
The SO-CSFP-1000BASE-BX20D-53-O2-I is a CSFP (Compact SFP) transceiver where both ports are bi-directional, i.e. providing double capacity as compared to normal BiDi transceivers where one port is not used. This requires that the host equipment support CSFP transceivers.
Each port operates directly on a single-fiber without the need for a separate optical filter. Each transceiver function uses a 1550nm transmitter and a receiver operating at 1310nm. The solution requires that the far end host equipment uses bi-directional SFP’s that transmit on a 1310nm wavelength and a receiver that accepts a 1550nm wavelength.
The transceiver supports a bit rate range between 100 Mbps and 1.25 Gbps, e.g. 1G Fiberchannel (1G FC) 100M Ethernet (FE) and 1G Ethernet (GbE) services, having an optical performance that provides a bridgeable distance of up to 20km.
Specification
- BiDi SFP form-factor with single LC connector
- Single-fiber operation
- Tx/Rx: 1550nm/1310nm
- Support for 100Mbps to 1.25Gbps
- Up to 20km distance, 14dB power budget
- Less than 1W power consumption per BiDi function
- I-temp operating conditions -40°C to +85°C.
